Metrology
It is our joint responsibility to satisfy requirements for our products and services as well as to comply with requirements and laws relating to occupational health, safety and environmental protection.
Quality
Products and Services
We impress our customers by providing the required quality. We strive to achieve the ‘zero defect’ goal for all our processes, products and services. Each employee is qualified to ensure that the specified processes and requirements comply with the applicable standards within the field of his/her responsibility.
We evaluate the performance of our processes using suitable indicators and relevant measurable objectives. We systematically analyze failure causes and solve them effectively and sustainably. We aim for lean processes and to avoid waste. We are committed to continuous improvement.
.jpg)
EQUIPMENT : CMM (CRYSTA APEX C- 574
Make : Mitutoyo
Features :
1) Auto & CNC programable measurment.
Parameter :
Length, Profile, Roundness, Straightness, Cylindricity, Parallalism, Runout, Diameter, Positional Accuracy
Basic measurement capability (+/-):
Accuracy : 1.9+3.0L/1000
Resolution : 0.1um
Range : X-650/Y-750/Z 500.
Traceability of calibration master : Mitutoyo Japan
EQUIPMENT : SURFACE FINISH TESTER ( ZEISS TSK (URF OM130A)
Make : Ziess
Features : STD.
Parameter : All surface parameter as per STD.
Basic measurement capability (+/-):
Accuracy : +/-9.2%
Resolution :+/-0.001 un
Traceability of calibration master : Zeiss Japan
.jpg)
EQUIPMENT : ROUNDNESS TESTER ( 365)
Make : Taylor Hobson.
Features :
1. CNC programmable measurment
Parameter :
Roundness, Straightness, Cylindricity, Coaxility, Squareness, Perpendicularity, Runout, Total runout & flatness
Basic measurement capability (+/-):
Accuracy : +/-0.02um.
Resolution : 0.01um.
Range : 200 X 300mm
Traceability of calibration master : Taylor Hobson USA.
.jpg)
EQUIPMENT : CONTRACER ( CV 300)
Make : Mitutoyo
Features : CNC programmable measurment.
Parameter :
Length , Profile of line, Radius , Distance.
Basic measurement capability (+/-):
Accuracy :
x-+/-(1.0+0.01l) um.
y - +/-(2.0+4h/100)um
Resolution : 0.1um
Range : 0 - 300mm
Traceability of calibration master : Mitutoyo Japan
.jpg)
EQUIPMENT : ROUNDNESS TESTER ( RONDCOM NEX)
Make : Zeiss
Features :
1. CNC programmable measurment
2. Surface finish measurment facility.
3. Small area surface finish measurement.MEASUREMENT
Parameter : Roundness, Straightness, Cylindricity, Coaxility, Squareness, Perpendicularity, Runout, Total runout & flatness.
Basic measurement capability (+/-):
Accuracy : +/-0.01um.
Resolution : 0.01um.
Range : 200 X 500mm
Traceability of calibration master : Zeiss (Japan).
EQUIPMENT : VIDEO MEASURING MACHINE
Make : Arcs
Features :
1. Manual measurment
Parameter :
Length, Width, Diameter, Distance.
Basic measurement capability (+/-):
Accuracy :
+/- 3.1 um (length).
+/-13 sec of arc.
Resolution : 1um.
Range : 0-300mm
Traceability of calibration master :MTI.
.jpg)
EQUIPMENT : ZYGO (NEW 7300 )
Make : Zygo (USA)
Features :
1. CNC programmable measurment.
2. Automated & programmable stages.
3. Automataed multi position system zoom & focus.
4. Active pneumatic vibration dumping.
5. High resolution & faster measurment.
6. 3D, non contact surface measurment.
Light source : White light led.
Illumination: Through the lens & objectives.
Parameter : Roughness, Waviness, Flatness, Curvature, Step height, Profile error, Radius.
Basic measurement capability (+/-):
Accuracy : Step height <=0.75%.
Resolution : Vertical < 0.1nm, lateral – 0.34um.
Range : 89 x 203 x 203mm, vertical scan range-150mm, extended-20mm weight 5kg.
Repetability :<0.01nm.
Traceability of calibration master : Zygo (USA).
